You can continue to crop your point cloud by changing the view, after which you can save and restore named cropping states. Commands, bugs and fixes, resources, help, tutorials, guides, tips and trix and updates. Need to downsize a bit? Point clouds can be so large they can be a little overwhelming! Use the Cropping panel (rectangular, polygonal, or circular) to clip your point clouds. Find out what AutoCAD 2018 can do and what the new features are.
Looking to use perpendiculars and centerlines? It’s super simple: Use Perpendicular to Edge to draw the perpendicular to the edge of two intersecting planes, and use Centerline to snap to the centerline of a cylindrical shape. You can use Edge if you want to snap to the edge of two intersecting planes, or Corner if you need to snap to the corner of three intersecting planes. You can use the Intersection object snap to snap to the apparent intersection of two lines of a sectioned point cloud. Object snap modes include practically everything you might need, including Intersection, Edge, Corner, Perpendicular to Edge, and Centerline!īe sure 3D Object Snap is displayed on the Status bar for easy access to the point cloud object snaps. If you have the 2018 version of those products, you can get this update from the Autodesk desktop app or by finding it in your Autodesk Account. Not only have many new object snaps been added for point clouds, but now you can control the point cloud object snaps from the 3D Object Snap tab in Drafting Settings. The 2018.1.2 update for AutoCAD and AutoCAD-based products including AutoCAD LT adds enhancements to xref layer properties, views and viewports, and high resolution (4K) monitor support.
#Autodesk autocad 2018.0.2 update whot is new portable
This week let’s continue to discuss some of the latest AutoCAD point cloud features! Object Snaps Showing 9 download results of 9 for Portable AutoCAD. Last week I mentioned some handy features that have been added to help with your point cloud needs.
